TM 5-3805-296-23-2
0093
Table 1. 0096 Fuel Level Sensor Diagnostic Code Continued.
093
CID FMI
TEST OR INSPECTION
CORRECTIVE ACTION
9. If removed, install instrument panel
0096-03 Fuel Level Sensor
cover (Figure 10, Item 3) with six
Voltage Above Normal
washers (Figure 10, Item 2) and
Continued
bolts (Figure 10, Item 1) on ROPS
(Figure 10, Item 4).
Figure 10. Instrument Panel Cover and Retaining Hardware.
0093
10. If removed, install lower and upper
plenum on ROPS (WP 0504).
11. If removed, install splash shield
(Figure 11, Item 4), four bushings
(Figure 11, Item 3), washers
(Figure 11, Item 2), and bolts
(Figure 11, Item 1) on machine.
Figure 11. Splash Shield and Retaining Hardware.
0093
