TM 5-3805-296-23-6
0388
INSTALLATION CONTINUED
NOTE
Route and install wire harness and tiedown straps as noted during removal.
16. Install 24-volt pulse receptacle unit wire harness (Figure 24, Item 3) and new tiedown straps
(Figure 24, Item 1) on hood assembly (Figure 24, Item 2).
17. Install 24-volt pulse receptacle unit (Figure 24, Item 8), two washers (Figure 24, Item 7), and bolts
(Figure 24, Item 6) on bracket (Figure 24, Item 9).
18. Install 24-volt pulse receptacle unit wire harness (Figure 24, Item 4) and new tiedown straps
(Figure 24, Item 5) on bracket (Figure 24, Item 9).
Figure 24. Tiedown Straps and 24-volt Pulse Receptacle Unit at Bracket.
0388
