74
TM 5-3805-296-23-5
FIELD MAINTENANCE
-
REAR BRAKE HOSES, TUBES, AND FITTINGS REPLACEMENT
0341
Cab Air Hoses Removal, Hitch Air Tubes Removal, Hitch Air Hoses Removal, Draft Frame Air Hoses
Removal, Bowl Air Hoses Removal, Cleaning and Inspection, Bowl Air Hoses Installation, Draft
Frame Air Hoses Installation, Hitch Air Hoses Installation, Hitch Air Tubes Installation, Cab Air
Hoses Installation
INITIAL SETUP
References
Tools and Special Tools
0
0
Tool Kit, General Mechanic's
WP 0539
0
(WP 0550, Item 181)
0
Equipment Conditions
0
Apron, Rubber Coated
Machine parked (TM 5-3805-296-10)
(WP 0550, Item 13)
0
0
Wheels chocked (WP 0454)
Gloves, Rubber (WP 0550, Item 74)
0
0
Brake system air pressure released
Wheel Chock (WP 0550, Item 192)
0
Wrench, Combination, 1-1/8"
0
Rear access panels removed (WP 0449)
(WP 0550, Item 196)
0
0
Rear hood removed (WP 0386)
Wrench, Combination, 1-1/4"
0
Right side scraper line guards removed
(WP 0550, Item 197)
0
(WP 0431)
Goggles, BII Item (TM 5-3805-296-10)
0
0
Ejector moved to full forward position
Materials/Parts
(TM 5-3805-296-10)
0
0
Cap Set, Protective, Dust
Drawings Required
(WP 0549, Item 6)
0
0
RPSTL Figures 94 and 96
Rag, Wiping (WP 0549, Item 28)
0
0
Sealing Compound, White (Pipe Thread)
Estimated Time to Complete
0
(WP 0549, Item 35)
0
10.3 hr
0
Tag, Marker (WP 0549, Item 38)
0
Tiedown Strap (WP 0549, Item 41)
0
0
0341-1
