TM 5-3805-296-23-4
0276
INSTALLATION CONTINUED
NOTE
Install wiring harness as tagged and marked during removal.
Install wiring harness as noted during removal.
Install new tiedown strap as noted during removal.
93. Install hydraulic filter bracket (Figure 55, Item 6) on machine.
94. Install harness bracket (Figure 55, Item 5) and ladder clip bracket (Figure 55, Item 2), four washers
(Figure 55, Item 4), and bolts (Figure 55, Item 3) on hydraulic filter bracket (Figure 55, Item 6).
95. Slide connector (Figure 55, Item 7) rearward and install on bracket (Figure 55, Item 5).
96. Install new tiedown strap (Figure 55, Item 1) on ladder clip (Figure 55, Item 8).
Figure 55. Rear of Transmission.
0276
