Table 1. Parking Brakes Do Not Engage Correctly Continued.
0113
MALFUNCTION
TEST OR INSPECTION
CORRECTIVE ACTION
Test Step 6. Inspect Front Brake
Parking Brakes Do Not
Actuators.
Engage Correctly
At both front wheels, verify brake
Continued
Both Front Actuators Not Extended
actuator (Figure 4, Item 1) is in
Proceed to Test Step 7.
extended position (Figure 4, Item 2).
Both Front Actuators Extended
Same as brake applied position noted
Replace tractor park brake pressure
previously.
switch (WP 0360).
Proceed to Test Step 15.
Figure 4. Front Brake Actuators.
0113
Test Step 7. Inspect Tractor Parking
Brake Air Hoses.
1. Turn ignition switch and battery
disconnect switch to OFF position
(TM 5-3805-296-10).
2. Using Compressed Air System
Air Hoses OK Replace front quick
Inspection as a guide (WP 0176),
release valve (WP 0332).
verify if air hoses between front
Proceed to Test Step 15.
brake actuators and quick release
Air Hose(s) Kinked or Damaged
valve are kinked or damaged.
Perform repair or replacement as
required by Compressed Air System
Inspection (WP 0176).
Proceed to Test Step 15.
