TM 5-3805-296-24P
0002
(1)
(2)
(3)
(4)
(5)
(6)
(7)
ITEM
DESCRIPTION AND USABLE ON
NO. SMR CODE
NSN
CAGEC
PART NUMBER
CODE (UOC)
QTY
GROUP AA ENGINE INSTALLATION
FIG. 7 OIL LEVEL DIPSTICK AND
TUBE.
PAFZZ
6880-01-604-8966
11083
378-0989
GAGE ROD,LIQUID LEV............................... 1
1
PAFZZ
5310-01-517-7869
11083
9X-6458
WASHER,FLAT 10.2X22.5X3-MM THK....... 1
2
PAFZZ
5306-00-252-8919
11083
0S0509
BOLT,MACHINE 3/8-16 X 0.75 IN............... 1
3
PAFZZ
4710-01-604-9028
11083
221-1871
TUBE ASSEMBLY,METAL............................ 1
4
PCFZZ
5331-01-554-3133
11083
118-5068
O-RING.......................................................... 1
5
PAFZZ
5340-01-053-4680
11083
1656170
PLUG,PROTECTIVE,DU............................... 3
6
END OF FIGURE
0002-17
