TM 5-3805-296-24P
0002
(1)
(2)
(3)
(4)
(5)
(6)
(7)
ITEM
DESCRIPTION AND USABLE ON
NO. SMR CODE
NSN
CAGEC
PART NUMBER
CODE (UOC)
QTY
GROUP AA ENGINE INSTALLATION
FIG. 5 ENGINE OIL FILTER AND
BASE.
PAFZZ
5340-01-604-9008
11083
7C4038
COVER,ACCESS.......................................... 1
1
PCFZZ
5330-00-216-8533
11083
2P4305
GASKET........................................................ 2
2
PAFZZ
2815-00-204-9666
11083
2P4301
BASE ASSEMBLY......................................... 1
3
PAFZZ
4820-01-322-6698
11083
9M0853
DISK,VALVE.................................................. 1
4
PAFZZ
5360-01-053-4656
11083
4N8150
SPRING......................................................... 1
5
PCFZZ
5330-00-222-0143
11083
2P3760
GASKET........................................................ 1
6
PAFZZ
5340-00-207-9110
11083
2P3761
COVER,ACCESS.......................................... 1
7
PAFZZ
5310-00-117-4788
11083
5M2894
WASHER,FLAT 10.2X18.5X2.5-MM THK.. 14
8
PAFZZ
5306-00-426-3949
11083
0S1588
BOLT,MACHINE 3/8-16 X 1.25 IN............... 6
9
PAFZZ
5365-01-062-5318
11083
9S-8006
PLUG,MACHINE THREAD............................ 1
10
PCFZZ
5331-01-562-1661
11083
238-5081
O-RING.......................................................... 1
11
PAFZZ
4330-01-604-9038
11083
2598357
ADAPTER,FLUID FILTE................................ 1
12
PAFZZ
5306-00-260-4508
11083
0S1594
BOLT,MACHINE 3/8-16X1 IN...................... 4
13
PAFZZ
5310-01-183-1237
11083
9S8752
NUT,PLAIN,HEXAGON 3/8-16 THD............ 4
14
PAFZZ
2805-01-604-9018
11083
1910965
DEFLECTOR,DIRT AND............................... 1
15
PAFZZ
2940-01-533-3470
11083
1R1808
FILTER ELEMENT,FLUI
16
ADVANCED EFFICIENCY............................. 1
PAFZZ
5305-00-253-5622
80205
MS21318-41
SCREW,DRIVE NO 8X03/8 IN..................... 2
17
PAFZZ
5306-01-094-9106
11083
0S1590
BOLT,MACHINE 3/8-16 X 2 IN.................... 2
18
PCFZZ
5331-01-513-5210
11083
214-7568
O-RING.......................................................... 2
19
PAFZZ
5340-01-352-7258
11083
8C3445
CAP,PROTECTIVE,DUST............................. 1
20
PAFZZ
4730-00-008-9818
11083
5P9617
REDUCER,BOSS.......................................... 1
21
PAFZZ
4730-01-508-4542
11083
6V8077
ELBOW,TUBE............................................... 1
22
PAFZZ
5307-01-604-9007
11083
2384664
STUD,SHOULDERED 3/8-16 THD.............. 1
23
PCFZZ
5331-01-524-4670
11083
214-7566
O-RING.......................................................... 1
24
PAFZZ
5365-01-042-9079
30780
4 HP5ON-S
PLUG,MACHINE THREAD............................ 1
25
PAFZZ
5305-01-026-9518
11008
0S1571
SCREW,CAP,HEXAGON H 3/8-16 X
26
1.75 IN........................................................... 1
END OF FIGURE
