TM 5-3805-296-24P
0002
(1)
(2)
(3)
(4)
(5)
(6)
(7)
ITEM
DESCRIPTION AND USABLE ON
NO. SMR CODE
NSN
CAGEC
PART NUMBER
CODE (UOC)
QTY
GROUP AA ENGINE INSTALLATION
FIG. 1 VALVE MECHANISM COVER
AND BASE.
PAFZZ
4030-01-536-7357
11083
243-1159
CHAIN FASTENER,FLAT............................ 18
1
PCFZZ
5325-01-536-9921
11083
149-7378
. GROMMET,NONMETALLIC........................ 1
2
PAFZZ
2815-01-585-9117
11083
239-4106
COVER,ENGINE POPPET............................ 1
3
PCFZZ
5330-01-534-1300
11083
242-9537
SEAL,PLAIN.................................................. 3
4
PAFZZ
2815-01-585-9065
11083
150-2557
COVER,ENGINE POPPET............................ 1
5
PAFZZ
2815-01-585-8876
11083
150-3136
COVER,ENGINE POPPET............................ 1
6
PCFZZ
5330-01-575-9623
11083
272-2583
. GASKET....................................................... 1
7
PAFZZ
2590-01-536-6637
11083
7C-6514
. CAP,FILLER OPENING............................... 1
8
PAFZZ
2930-01-604-9302
11083
253-0552
CAP,FILLER OPENING................................. 1
9
PAFZZ
5306-01-564-4846
11083
122-1472
BOLT,MACHINE 5/16-18X2.36 IN............... 1
10
PAFZZ
2815-01-585-8521
11083
289-8215
HOUSING,ROCKER ARM............................. 1
11
PCFZZ
5330-01-588-0805
11083
272-0390
SEAL,PLAIN ENCASED................................ 1
12
PAFZZ
5306-01-604-9031
11083
3565212
BOLT,MACHINE.......................................... 12
13
PAFZZ
4730-01-066-4586
11083
8M-0505
ADAPTER,STRAIGHT,TU............................. 1
14
PCFZZ
5331-01-413-2754
11083
6V6609
O-RING.......................................................... 1
15
PAFZZ
4210-01-564-4238
11083
207-8128
HOSE ASSEMBLY,NONME.......................... 1
16
PAFZZ
5340-01-564-4840
11083
161-6622
CLAMP,LOOP................................................ 1
17
PAFZZ
5306-00-252-8919
11083
0S0509
BOLT,MACHINE 3/8-16 X 0.75 IN............... 1
18
PAFZZ
5310-00-117-4788
11083
5M2894
WASHER,FLAT 10.2X18.5X2.5-MM THK.... 1
19
PAFZZ
4730-00-204-3491
58536
A-A-52506-F-32
CLAMP,HOSE............................................... 1
20
PAFZZ
5325-01-438-1391
11083
5P2369
FASTENER,POSITIVE L............................... 1
21
PAFZZ
5306-00-165-1934
11083
9L8925
BOLT,MACHINE 5/16-18X1.25 IN............. 14
22
END OF FIGURE
0002-3
