SCRAPER SYSTEM AIR PRESSURE SENSOR DIAGNOSTIC CODES
Table 1. 1430 Scraper System Air Pressure Diagnostic Codes Continued.

Field Maintenance Manual For Military 621G Scraper -2 Page Navigation
  310    311    312    313    314  315  316    317    318    319    320
.
TM 5-3805-296-23-2
0085
Table 1. 1430 Scraper System Air Pressure Diagnostic Codes.
0085
CID FMI
TEST OR INSPECTION
CORRECTIVE ACTION
NOTE
1430-03 Scraper Air
Pressure Sensor Voltage
Always inspect harness connectors that are involved in the circuit. Poor
Above Normal
connections can often be the cause of a problem in an electrical circuit.
Verify that all connections in the circuit are clean and secure and that all
connections are in good condition. If a problem with the connection is
found, correct the problem and verify that this malfunction or diagnostic
code is active before performing this procedure.
Perform open or short-circuit test at each harness connection to identify
the correct harness to replace.
Tag all wiring harnesses to aid in installation.
Perform this test only if condition is active.
DIAGNOSTIC CODE SET CONDITION
Transmission/Chassis ECM Detects Above Normal Voltage on Scraper Air
Pressure Sensor Circuit C457.
POSSIBLE CAUSE
Push Frame Wiring Harness High Resistance, Open, or Shorted.
Draft Frame and Bowl Side Wiring Harness High Resistance, Open, or
Shorted.
Hitch Wiring Harness High Resistance, Open, or Shorted.
Chassis Wiring Harness High Resistance, Open, or Shorted.
Main Cab Wiring Harness High Resistance, Open, or Shorted.
Scraper Air Pressure Sensor.
Transmission/Chassis ECM.
Test Step 1. Test Scraper Air
Pressure Sensor Circuit, Battery +
Circuit, and Ground Circuit Function.
1. Turn ignition switch and battery
disconnect switch to OFF position
(TM 5-3805-296-10).
2. Disconnect connector AF-C4
(WP 0012, Figure 168) from
scraper air pressure sensor
connector (WP 0012, Figure 167).
3. Turn battery disconnect switch and
ignition switch to ON position
(TM 5-3805-296-10).
4. Using digital multimeter
Voltage Greater Than 5.8 V Proceed
(WP 0540), test for voltage
to Test Step 2.
between connector AF-C4
Voltage 4.5 to 5.8 V Proceed to step
terminal C and terminal B
5.
(WP 0012, Figure 168).
Voltage Less Than 4.5 V Proceed to
Test Step 8.
0085-2
