Table 1. 1278 Apron Lower Proportional Solenoid Diagnostic Codes Continued.
073
CID FMI
TEST OR INSPECTION
CORRECTIVE ACTION
3. Remove four bolts
1278-05 Apron Lower
(Figure 5, Item 2), washers
Solenoid Current Below
(Figure 5, Item 1), and cover
Normal Continued
(Figure 5, Item 3) from machine.
Figure 5. Cover.
0073
4. Disconnect connector F-C1
(WP 0012, Figure 148) from apron
lower solenoid connector
(WP 0012, Figure 147).
5. Connect jumper wire between
terminal 1 and terminal 2
of connector F-C1
(WP 0012, Figure 148).
6. Turn battery disconnect switch and
ignition switch to ON position
(TM 5-3805-296-10).
7. At MSD, check for active
1278-6 Apron Lower Solenoid
diagnostic code 1278-5 Apron
Current Above Normal Becomes
Lower Solenoid Current Below
Active Replace apron lower solenoid
Normal (WP 0008).
(WP 0434).
Proceed to Test Step 6.
1278-5 Apron Lower Solenoid
Current Below Normal Remains
Active Proceed to Test Step 2.
