TM 5-3805-296-10
0014
UNBLOCKING APRON
00014
1. Start engine (WP 0005).
2. Open apron (WP 0004).
3. Shut down engine (WP 0005).
4. Remove bolt (Figure 4, Item 2), washer (Figure 4, Item 3), and pin (Figure 4, Item 1) from bowl frame
(Figure 4, Item 4).
5. Start engine (WP 0005).
6. Close apron (WP 0004).
7. Shut down engine (WP 0005).
Figure 4. Inboard Pin Mount.
0014
8. Install pin (Figure 5, Item 3) into storage location, washer (Figure 5, Item 2), and bolt (Figure 5, Item 1) on bowl
frame (Figure 5, Item 4).
Figure 5. Stowed Pin.
0014
END OF TASK
END OF WORK PACKAGE
0014-3/(4 blank)
