TM 5-3805-296-10
0004
OPERATOR CONTROLS AND INDICATORS CONTINUED
KEY
COMPONENT
DESCRIPTION
1
Service Brake Control Pedal
Push pedal downward to engage service brake, reduce
ground speed, and stop machine.
Release pedal to disengage service brake.
N OT E
2
Governor Control Pedal
Depressing governor control pedal will not
increase engine speed of scraper unless air
pressure is above 60 psi (414 kPa).
Push pedal downward to increase engine and travel speed.
Release pedal to decrease engine and travel speed.
3
Differential Lock Control Switches
Switches located on floor, one on each side of foot controls.
Push switch down and hold to engage differential lock.
Release switch to disengage differential lock.
4
Foot Rest
Provides place to rest foot.
0004-15
