TM 5-3805-296-23-2
0129
Table 1. Apron Moves in One Direction Only, All Other Implements Operate Normally.
0129
MALFUNCTION
TEST OR INSPECTION
CORRECTIVE ACTION
NOTE
Apron Will Raise, But Will
Not Lower, All Other
Proceed directly to Test Step 2 if sent here by Implement, Cushion Hitch,
Implements Operate
and Steering System Operation Test.
Normally
Test Step 1. Verify Malfunction is
Active.
Perform Implement, Cushion Hitch,
Cause of Malfunction Identified and
and Steering System Operation Test
Repaired During Testing
(WP 0172).
Troubleshooting complete.
Cause of Malfunction Not Identified
During Testing, Malfunction Active
Proceed to Test Step 2.
Test Step 2. Perform Corrective
Action.
Apron lower solenoid
Replace apron lower solenoid
malfunctioning.
(WP 0435).
NOTE
Apron Will Lower, But Will
Not Raise, All Other
Proceed directly to Test Step 2 if sent here by Implement, Cushion Hitch,
Implements Operate
and Steering System Operation Test.
Normally
Test Step 1. Verify Malfunction is
Active.
Cause of Malfunction Identified and
Perform Implement, Cushion Hitch,
Repaired During Testing
and Steering System Operation Test
(WP 0172).
Troubleshooting complete.
Cause of Malfunction Not Identified
During Testing, Malfunction Active
Proceed to Test Step 2.
Test Step 2. Perform Corrective
Action.
Apron raise solenoid malfunctioning.
Replace apron raise solenoid
(WP 0434).
END OF WORK PACKAGE
